Compatibility, System Requirements, Hardware Specifications
SYSTEM REQUIREMENTS
Mac OS X 10.7 or 10.8 (latest update), Intel Core 2 Duo, 2 GB RAM (4 GB recommended)
SUPPORTED DRIVERS
- ASIO
- Core Audio
- DirectSound
- WASAPI
SUPPORTED AUDIO FORMATS
AUDIO INTERFACE DIMENSIONS
Weight: 950g / 2,09 lbs
HARDWARE SPECIFICATIONS
Audio Converters: | |
---|---|
Channels (A/D, D/A) | 10, 10 |
Sample Rates | 44.1, 48, 88.2, 96 kHz |
Bit Resolution | 16, 24 Bit |
Converter | Cirrus Logic |
Line Inputs: | |
Input Impedance | 47 kOhm |
A/D-D/A to Output: | |
Full Scale Input Level | +12 dBu, 3.08 Vrms |
Gain | -2.6 dB |
Dynamic Range | 98.4 dB (A) |
THD+N (Full Scale Level) | 0.027 % |
Frequency Response (96 kHz), -1 dB | 13 Hz - 45 kHz |
Direct Thru: | |
Maximum Input Level | +13.2 dBu, 3.5 Vrms |
Gain | -4.7 dB |
Dynamic Range | 105.5 dB (A) |
THD+N (Maximum Level) | 0.0026 % |
Frequency Response, -1 dB | 13 Hz - 70 kHz |
Phono Inputs: | |
Input Impedance | 47 kOhm |
A/D-D/A to Output: | |
Full Scale Input Level @ 1 kHz | -22.2 dBu, 60 mVrms |
Gain @ 1 kHz | +31.5 dB |
Dynamic Range @ 1 kHz | 95.7 dB (A) |
THD+N @ 1 kHz | 0.03 % |
Frequency Response | IEC curve +/- 1 dB |
Direct Thru: | |
Maximum Input Level @ 1 kHz | -16.2 dBu, 120 mVrms |
Gain @ 1 kHz | +29.1 dB |
Dynamic Range @ 1 kHz | 95.9 dB (A) |
THD+N @ 1 kHz | 0.02 % |
Frequency Response | IEC curve +/- 1 dB |
Line Outputs (D/A): | |
Full Scale Output Level | +9.6 dBu, 2.35 Vrms |
Dynamic Range | 102.1 dB (A) |
THD+N | 0.015 % |
Frequency Response (96 kHz), -1 dB | 8 Hz - 45 kHz |
Headphone Output: | |
Maximum Output Level @ 10 kOhm | +13.3 dBu, 3.55 Vrms |
Maximum Output Power | 40 mW @ 100 Ohms, 15 mw @ 33 Ohms |
THD+N (Maximum Level, 100 Ohms) | 0.013 % |
Frequency Response (96 kHz), -1 dB | 10 Hz - 45 kHz |
