Features

    CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AAC Yes / Yes / Yes / Yes / Yes / Yes
    CD-Text / SA-CD Text / ID3 Tag / WMA Meta Tag / AAC Meta data No / Yes / Yes / Yes / Yes
    Data Disc Compatibility: DSD / WAV / ALAC <=5.6 / 192 / 96
    DAC operation mode: USB B type / Coax / Optical Yes / Yes / Yes
    Asynchronous mode rear USB Yes
    Bit-perfect transmission Yes
    USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 <=DSD11.2
    Signal isolator for DAC Mode operation Yes
    HDAM version HDAM SA2 + HDAM SA3
    Power Transformer: Toroidal / El Yes / No
    High Grade Audio Components Yes
    Customised Components Yes
    Symmetric circuit layout Yes
    Copper Plated Chassis No
    Extra metal plate for chassis strengthing Yes
    Digital out off / Audio EX Mode Yes / No
    Headphone: Standard / Buffer / Current feedback No / No / Yes

Others

    Selectable filter: CD / SA-CD / DAC-Mode Yes / No / Yes
    Marantz Musical Mastering Yes (HD)
    Marantz Musical Mastering Stream Yes
    Marantz Musical Mastering Conversion Yes
    Separated rectifier circuit for analogue and digital circuitry Yes
    Display: Dimmer / Off No / Yes
    Low noise LCD display Yes
    5mm Aluminum top cover No

Playback

    Program Play (CD / SA-CD) Yes / Yes
    Repeat Yes
    Random Play Yes
    Start Sound Mode for SA-CD Yes

Inputs Outputs

    Analogue Out (Cinch) 2ch
    Balanced Out No
    Digital Optical In / Out 1 / 1
    Digital Coaxial In / Out 1 / 1
    Sample Rate digital In 192 kHz / 24-bit
    Gold Plated Cinch silver / nickel
    USB Audio (Front) / Made for iPod / Made for iPhone® rear / No / No
    USB-A: FLAC / WAV / AIFF / ALAC / DSD Yes / Yes / Yes / Yes / Yes
    USB type B input for PC (rear) Sample Rate USB type B In Yes
    Asynchronous mode rear USB Yes
    USB type B input for PC (rear) 384 kHz / 32-bit
    USB-B DSD Audio Streaming (DoP): DSD2.8 / DSD5.6 -> DSD11.2
    D-Bus Yes
    Headphone Out Yes
    Headphone Volume Control Yes

Specifications

    Mechanism SACD-M3 (METAL)
    D/A Conversion Marantz Musical Mastering Conversion + Stream
    DAC IC Marantz Musical Mastering Conversion + Stream
    Digital Filter DSP (Marantz)
    Noise Shaper DSP (Marantz)
    Low Pass Filter stage HDAM-SA2, SA3 current feedback
    Output Buffer HDAM SA3
    Headphone amp HDAM-SA2 current feedback
    Frequency Response (Cust.) 2 Hz - 50 kHz
    Dynamic Range (SA) 109dB
    Signal to Noise Ratio (SA) 112dB
    Total Harmonic Distortion (SA) 0.0008%
    Channel Separation (SA) No
    Frequency response 2 Hz - 20 kHz
    Dynamic Range 98 dB
    Signal to Noise Ratio 104 dB
    Total Harmonic Distortion 0.000015
    Channel separation No

General

    Metal Front Panel Yes
    Remote Control RC005PMSA
    Power Consumption in W 47
    Standby Consumption in W 0.3
    Auto Power off Yes
    Detachable Power Cable Yes
    Maximum Dimensions (W x D x H) in mm 440 x 419 x 123
    Weight in kg 16.4
    Carton Maximum Dimensions (W x D x H) in mm 557 x 536 x 243
    Carton Weight (inc. product) in kg 19.6
