Denon AVC-X 8500HA Silver - AV Risiver
Upgrade your expectations in home theater and audio entertainment with the AVC-X8500HA. The worlds first 13.2Ch 8K AV receiver.
• 13.2 channels
• 210 watts per channel
• 8K Ultra HD
• 3D Audio
• HEOS Built-in
• 8 HDMI inputs
Multichannel Surround
IMAX Enhanced: Yes
DTS HD Master / DTS:X: s / Yes
DTS Neo:X / DTS Neural:X: / Yes
DTS Virtual:X: s (update)
Dolby TrueHD / Dolby Atmos: s / Yes
Dolby ProLogic Il / Dolby Surround: / Yes
Auro 3D: s
Multichannel Stereo: s
Max Number of Processing (Preamp) Channels: 13.2
Sound Enhancements
Mono Block Power Amp Construction: Yes (L/R separated)
Discrete Power Amplifier: 13
D.D.S.C. HD Digital: Yes (32 bit)
Pure Direct: Yes
High Grade Audio Components: Yes
Gold-Plated RCA Terminals: Yes
Clock Jitter Reducer: Yes
Alpha Processing: AL32 Processing Multichannel
Denon Link HD: Yes
Audyssey: MultEQ XT32
Audyssey Dynamic EQ / Dynamic Volume: Yes / Yes
Audyssey LFC: Yes
Audyssey APP Support: Yes
Compressed Audio Restorer: Yes
Network
HEOS Multiroom and Streaming: Yes
Lossy Formats: MP3 / WMA / AAC: Yes / Yes / Yes
Lossless Formats: FLAC / ALAC / WAV: Yes / Yes / Yes
DSD Audio Streaming: up to DSD5.6
FLAC HD 192/24: Yes
WAV 192/24: Yes
ALAC 192/24: Yes
Gapless playback: Yes (FLAC, WAV, ALAC, DSD)
AirPlay Audio Streaming: Yes
Internet Radio: TuneIn
Spotify Connect* / Tidal* / Deezer* / others *: Yes / Yes / Yes / Yes
Compatible with Remote APP for Smart Phones: Android / iOS
Compatible with Remote APP for Tablets: Android / iOS/Amazon Kindle
Ethernet Ports: Yes
Wi-Fi: Yes
Bluetooth: Yes
AirPlay 2: Yes (update)
HDMI
HDMI Inputs: Back / Front: 7 / 1
HDCP2.3 support: Yes
HDMI Outputs: Main / Zone: 2 / 1
HDMI max Resolution (8k / 4k): 8k/60 - 4k/120**
Video Conversion Analog -> HDMI: Yes
HDMI to HDMI Scaling: up to 8K 60/50
HDMI: 8K / 4K / CEC / eARC: Yes / Yes / Yes / Yes
HDMI: Dolby Vision / HDR 10+ / Dynamic HDR / HLG: Yes / Yes / Yes / Yes
HDMI: ALLM / QMS / QFT / VRR: Yes / Yes / Yes / Yes
HDMI pass-though in standby mode: Yes
DSD Audio Capability: Yes
Multi-room / CI
HEOS Multiroom integrated: Yes
TV Sound grouping: Yes
Multi-Room Zones: 3
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog: Yes (2ch) / Yes (2ch) / Yes / Yes
Zone Audio Output: Speaker / Preout: Yes / Yes
Zone HDMI Output from HDMI Source: Yes
IP Control / RS232 Control / Web Control / App Control: Yes / Yes / No / Yes
Remote In / Out: Yes / Yes
DC Trigger Output: 2
Others
Auto Speaker Setup by Microphone: Audyssey MultEQ XT32
FL Display: 2 lines
Graphic User Interface - GUI: Advanced
ISF Certification: Yes
GUI Languages: 9
Setup Assistant: Yes
Quick Select Plus / Quick Select: Yes / No
Firmware Update by: Network / USB: Yes / Yes
Variable Cross Over: Yes
Optimized Bass Redirection: Yes
Bass Sync: Yes
ECO Mode: Yes
Auto Power Off: Yes
Sleep Timer: Yes
Inputs/Outputs
Composite In / Out: 4 / 2
Component In / Out: 3 / 1
HDMI In / Out: 7+1 / 3
Multi-room Video Out: Video / HDMI: Yes / Yes
Analogue In/out: 6+1 / No
Phono (MM) In: Yes
Digital In: Optical / Coaxial: 2 / 2
Multi-room Out: Analog / Digital: 2 / No
Multichannel Pre-Out: Yes (15.2)
Subwoofer Out: 2 (independent)
7.1 Multichannel Input: Yes
Speaker Terminal: Gold Plated Screw / Regular Screw: Yes / No
Number of Speaker Terminals: 15
Speaker A/B / Bi-amp Drive / Multi-Room Speaker: assignable
Speaker A / B: assignable
Bi-amp Drive: assignable
Multi-Room Speaker Terminal: assignable
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB: No / No / No / Yes / Yes
USB Audio / Made for iPod / Made for iPhone: Yes / AirPlay / AirPlay
Specifications
Number of Power Amps: 13
Power Output (8 ohm, 20Hz - 20kHz, 0.05% 2ch Drive): 150 W
Power Output (6 ohm, 1kHz, 0.7% 2ch Drive): 190 W
Power Output (6 ohm, 1kHz, 1% 1ch Drive): 210 W
General
Available colors: Black / Premium Silver: Yes / Yes
Metal Front Panel: Yes
System Remote Control: RC-1221
Pre-programmed / Learnable / LCD Display: Yes / Yes / Yes
Power Consumption in W: 900
Power Consumption No-Sound (ECO On / Off) in W: 70 W / 125 W
Standby Consumption in W: 0.1
CEC Standby Consumption in W: 0.5
Network Control On Consumption in W: 3.7
Maximum Dimensions:
• Antenna: Horizontal: (W x D x H) in Inches: 434 x 482 X 195
• Antenna: Vertical: (W x D x H) in Inches: 434 x 482 X 259
• W/O Antenna: (W x D x H) in Inches: 434 x 472 x 195
Weight in kg: 23.3
