POWER AND AMPLIFICATION:
• 9*170 W (6ohms, 1 kHz, 1% THD, 1-ch driven, IEC)
• 9 channels amplifier
• Class AB Amplifier
• 5Hz-100kHz (+1/-3dB)
• 9.2ch Processing

HDMIAND VIDEO INPUTS
• 6 In / 2Out (eARC)
• 8K/4K Ultra HD
• Dolby Vision, HDR10+, HDCP2.3, HDMI2.1aVRR, QFT, ALLM, SBTM
• 1component, 2 composites

AUDIO IN/OUT
• 6 RCA, 1RCA Phono
• 1Opt, 1Coax
• 9.2 ch preouts(2 Independent subwoofer outputs)
• Zone 2 Stereo RCA

SURROUND MODES
• Dolby Atmos, Dolby Surround
• DTS:X, Neural:X
• IMAX Enhanced

STREAMING
• Roon Tested
• Chromecast built-in
• AirPlay 2
• Spotify
• Amazon Music HD
• Tidal
• Deezer
• TuneIn

KEY FEATURES
• Wi-Fi/Bluetooth®
• Dirac Live® Room Correction Full Bandwidth License Included
• Optional Dirac Live® Bass Control
• Works with Sonos - w/Volume Pass-Through
• THX® Certified for Theater Reference Sound
• Klipsch Optimized Mode

GENERAL INFORMATION
• Product Dimension (WxHxD): 435 x 177.5 x 382.5 mm / 17.1 x 7 x 15.1 inch
• Packaging Dimension (WxHxD): 540 x 270 x 467 mm / 21.3 x 10.6 x 18.4 inch
• Net Weight of product: 11,5 kg / 25,4 lbs
• Gross Weight of product: 14.5 kg / 32 lbs

POWER COMSUMPTION
• 760W
• 50W Idle <2W Network standby

SKU
• TX-RZ30BMMM

EAN CODE
• 4573211155716
