60W per channel
    HEOS® Built-in
    HDMI ARC
    Marantz HDAM® circuits
    Hi-Res audio support
    CD and MM phono inputs


Amplifier

    Channels 2
    PSU Transformer Toroidal
    Speaker A / B No
    Speaker Terminals Marantz SPKT-1+
    Number of Terminals 2
    Power Output (8 / 4 Ohm RMS) 60 W / 80 W
    Topology Class A/B

Audio Components and Technologies

    Current Feedback Topology Yes
    HDAM Version SA3, SA2
    High Grade Audio Components Yes
    Customised Components Yes
    Symmetric PCB Layout Yes
    Aluminium Extrusion Heat Sink Yes
    Copper Plated Chassis No
    Marantz Musical Digital Filtering No
    Linear Drive Power Supply Yes
    BI-AMP and Multichannel Option No
    Shottky Diodes Yes

Control

    D-Bus Yes

DAC

    Digital Inputs Coaxial, Optical, USB-A
    Max PCM Sample Rate 192 kHz / 24-bit
    Max DSD Sample Rate DSD 4X (11.2 MHz)
    HDMI 1 ARC

HEOS

    Streaming Technologies Bluetooth, Airplay 2, Roon Ready, Spotify Connect, Tidal Connect
    Streaming Services (subject to change and local availability) Tidal (Hi Res), Deezer (Hi Res), Amazon Music HD, Pandora, TuneIn, iHeartRadio, SoundCloud, SiriusXM, AWA, Mood:Mix, Qplay, Sony HiRes
    HEOS Multiroom and Streaming Yes
    Lossy Formats MP3, WMA, AAC
    Lossless Formats DSD/DSF, FLAC, ALAC, WAV
    Gapless Playback Yes
    HEOS App iOS, Android

Network

    Wi-Fi / Wired LAN Yes / Yes

Other

    Display Low-Noise OLED Monochrome

Preamp

    Phono EQ MM Standard
    Tuner: FM / AM No
    Audio Adjustments Yes
    Power Amp Direct No
    Balanced In / Out No / No
    Preamp Outputs 1
    Subwoofer Output 1 Mono
    Headphone Out Yes

Specifications

    Frequency Response 5 Hz-100 kHz
    Total Harmonic Distortion 0.02 %
    Damping Factor 100<
    Input Sensitivity: MM 1.9 mV / 47 kOhm
    Signal to Noise Ratio: MM/MC 87 dB / -
    Input Sensitivity: High Level 190 mV / 20 kOhm
    Signal to Noise Ratio: High Level 113dB
    Treble Control ± 10 dB at 15kHz
    Bass Control ± 10 dB at 50Hz
    Metal Front Panel Yes
    Power Consumption in W 220
    Standby Consumption in W 0.3
    Auto Power Off Yes
    Detachable Power Cable Yes
    Remote Control RC006PM
    System Remote Function Yes
    Maximum Dimensions (W x D x H) mm 442 x 431 x 129
    Carton Maximum Dimensions (W x D x H) mm 527 x 517 x 255
    Carton Weight (inc. product) in kg 15.5
    Maximum Dimensions (W x D x H) in 17.4 x 17 x 5.1
    Weight in LBS 28.1
    Carton Maximum Dimensions (W x D x H) in 20.8 x 20.4 x 10.1
    Carton Weight (inc. product) in LBS 34.3
