Marantz PM6007/N1 Silver Gold Integrisano Pojačalo
*Cena sa popustom može da se ostvari ukoliko se plaća gotovinski, virmanom (preko računa) ili odmah debitnom i kreditnom karticom.
Garantujemo najnižu cenu!
- Futoški put 1, Novi Sad
- Svetogorska 9, Beograd
The PM6007 delivers Marantz’ most musical sound and is an ideal choice for those ready to take the next step in their 2-channel Hi-Fi system. Powered by a Toroidal power transformer and customized block capacitors, the PM6007 integrated amplifier delivers 45 watts (8ohm, 20Hz-20kHz) of power-per-channel. You can easily connect both analogue and digital sources or connect your turntable to the built-in phono pre-amplifier. Listen to your favourite Hi-Res audio content through the 192-kHz/24-bit D/A converter and experience enhanced bass with a subwoofer-out option.
Marantz maintains a steadfast reputation for choosing the best possible components for its Hi-Fi products, and the PM6007 is built with that same performance-first Hi-Fi approach. Marantz engineers selected and improved the PM6007 versus the previous PM6006 through extensive listening in dedicated Marantz facilities in Europe and Japan using Hi-Fi tuned sound parts. For example, increasing the size of the power supply capacitors by 20% improved stability during high demand listening sessions.
- The PM6007 integrated current feedback amplifier powers 2x 45W (8 ohms RMS, 20Hz – 20kHz)
- Wide range of connectivity including five analogue inputs, one coaxial input and two optical digital inputs
- Digital filter modes for optical and coaxial inputs
- The newly updated, high-quality DAC AK4490 offers a richer sound for your enjoyment
- No memory distortion for clean and precise audio reproduction even after powerful bass attacks
- A high-quality MM phono pre-amp with FET input to enjoy the signal purity from your vinyl
- Enjoy deeper bass using an optional external subwoofer with a fixed low pass cut off frequency at 150Hz
- In addition to high-quality speaker terminals with A/B switching capability, a fully-shielded DAC unit, and copper screws, the rigid feet provide a true-to-performance sound
Current Feedback Amplifier
The Current Feedback Amplifier technology provides wide-bandwidth and high-speed sound reproduction. In combination with the high current power supply, the PM6007's amplifier section holds a large energy reserve to easily drive even the most demanding speakers. An advanced thermal compensation avoids memory distortion for clean amplification under any circumstances.
The Hyper Dynamic Amplifier Module consist of discrete surface mount components with short mirror image L/R signal paths. These devices do exactly the same thing as the Op-amps, but outperform these solutions dramatically in terms of the Slew Rate and reduced noise level, resulting in more dynamic, accurate and detailed sound.
In the PM6007, the HDAM-SA3 circuit improves on its previous module and the idling current stability is less influenced by power transistor temperatures to maintain sound performance even at high level output.
Reference D/A Conversion
The PM6007 features a new Hi-Res D/A conversion. It is equipped with a reference class AK4490 D/A converter, which provides up to 192-kHz/24-bit resolution for optimum fidelity with your Hi-Res audio file types.
High Current Power Supply
The power supply supports high current, high speed Shottky Barrier Diodes and high current storage capacitors fed by a Toroidal Transformer that together provide wide dynamic range and low impedance drive capability.
Toroidal Transformer
The highly efficient design of the Toroidal Transformer delivers more power compared to the same size EI core transformer. The shape lowers electromagnetic radiation and mechanical vibration for better sound quality.
Features
Channels |
2 |
Current Feedback Topology |
Yes |
Phono EQ |
Standard |
Sample Rate Digital In |
192kHz / 24-bit |
DAC Chip |
AK4490 |
HDAM Version |
SA3 |
Power Transformer |
Toroidal |
High Grade Audio Components |
Yes |
Customised Components |
Yes |
Symmetrical PCB Layout |
No |
Aluminium Extrusion Heat Shrink |
Yes |
Copper Plated Chassis |
No |
Balance / Bass / Treble / Loudness |
Yes / Yes / Yes / No |
Other
Marantz Musical Digital Filtering |
Yes |
Linear Drive Power Supply |
Yes |
Linear Volume Control |
Yes |
BI-AMP And Multichannel Option |
No |
Shottky Diodes |
Yes |
Source Direct |
Yes |
Power Amp Direct |
No |
Inputs / Outputs
Audio Inputs |
5 |
Digital In |
2 Optical |
Phono Input |
MM |
Audio Outputs |
1 |
Pre-Out |
Subwoofer |
Power Amp Direct IN |
No |
Gold Plated Cinch |
Yes |
Speaker A/B |
Yes |
Speaker Terminals |
Metal (Gold) Screw |
Number Of Terminals |
4 |
D-Bus |
Yes |
Headphone Out |
Yes |
Specifications
Power Output (8 / 4 Ohms RMS) |
45 W / 60 W |
Frequency Response |
10 Hz - 70 kHz |
Total Harmonic Distortion |
0.08% |
Damping Factor |
100 |
Input Sensitivity: MM |
2.2 mV / 47 kOhm |
Signal To Noise Ratio: MM |
83 dB |
Input Sensitivity: High Level |
200 mV / 20 kOhm |
Signal To Noise Ratio: High Level |
102 dB (2V Input) |
General
Available Colours |
Black / Silver-Gold |
Metal Front Panel |
Yes |
Power Consumption |
155 W |
Standby Consumption |
0.3 W |
Auto Power Off |
Yes |
Detachable Power Cable |
RC004MCD |
System Remote Function |
Yes |
Dimensions (W x D x H) |
440 x 370 x 105cm |
Carton Dimensions (W x D x H) |
517 x 468 x 189cm |
Weight |
7.8kg |
Carton Weight (Incl. Product) |
9.7 kg |
