DSi Amplifier for JBL Cinema Loudspeakers
• 96kHz/32-bit floating-point processing with FIR filtering, LevelMAX limiting, 8-channel
parametric EQ, and delay
• Dante/AES67 support for seamless integration with Dolby Atmos Connect
• Four channels with bridgeable outputs
• Built-in JBL cinema speaker tuning presets to match all JBL cinema loudspeakers
• SNMP to interface with third party Theater Management and Cinema Control (NOC)
systems
• HiQnet port
• Rated power @8 Ohms (1kHz, 20ms burst, 2 channels driven, 0.5% THC Max): 350W x 4
• Rated power @4 Ohms (1kHz, 20ms burst, 2 channels driven, 0.5% THC Max): 700W x 4
• Rated power @2 Ohms (1kHz, 20ms burst, 2 channels driven, 0.5% THC Max): 1,050W x 4
• Rated power @8 Ohms Bridged (1kHz, 20ms burst, 2 channels driven, 0.5% THC Max):
1,300W x 2
• Rated power @4 Ohms Bridged (1kHz, 20ms burst, 2 channels driven, 0.5% THC Max):
2,200W x 2
• Dimensions (H x W x D): 3.46” x 18.98” x 17.21” (88mm x 482mm x 437mm)
• Weight: 23.15 lb (10.5kg)
