Class D Subwoofer Amplifier
• Rated Output Power (RMS) into the minimum impedance of 4 Ohms: 700Watts
• Peak power: 1500W
• Rated impedance: 8Ohms per speaker output
• Minimum load impedance: 4Ohms
• Model-Specific EQ: 1: Only for JBL SYNTHESIS SSW-4 2: Only for JBL C82W
• Input Sensitivity to 1W @ 50Hz: 16.3mVrms +/- 1dB (Single input driven) Gain=41.7dB
• Input Overload (Both inputs driven): ≥ 2.0Vrms
• Input Impedance: > 10K Ohms
• Low Pass Crossover range: 50-150Hz
• Auto Turn On Input Sensitivity @ 50Hz: Typical 10mV
• THD+N at 1W: < 0.3%
• THD+N at Rated Output Power: < 1%
• Signal-to-Noise ratio to 1W: > 65dBA
• Minimum AC Mains power requirements: 100-120VAC-50-60Hz Model: 700W, 5A
230VAC-50-60Hz Model: 700W, 3A
• Power consumption (Standby): 0.5W
• Dimensions (H x W x D) 3.50 x 17 x 11.04 in (88.90 x 431.8 x 280.3 mm)
• Weight: 14Lb (6.35Kg)
