Type: 2.5-Way In-wall loudspeaker
• Low Frequency Driver: Four 5.25” (130 mm) advanced Aluminum Matrix cone cast-frame woofers
(JW13Al-4)
• High Frequency Driver: 1” (25 mm) 2410H-2 Teonex® annular ring-diaphragm compression driver
• Recommended Amplifier Power: 25 – 200W RMS
• Impedance: 4 Ohm
• Loudspeaker Sensitivity: 91 dB/2.83V/1m
• Frequency Response: 50Hz - 30kHz (-6 dB on-axis), 2pi anechoic
• Crossover Frequency: 1.8 kHz
• High Frequency Coverage Angle (-6 dB): 80° Vertical / 80° Horizontal, from 2 kHz to 17 kHz.
• Enclosure Type: Open back
• Controls: Boundary Proximity Control
• Grille Dimensions: 7.29” (185 mm) x 31.32” (796 mm)
• Product Dimensions (grille): 7.29” (185 mm) x 31.32” (796 mm) x 3.82” (97.1 mm)
• Cut-out Dimensions: 5.95” (151 mm) x 29.98” (761 mm)
• Rough-in Bracket: WB54
• Mounting Depth: 3.63” (92 mm)
• Input Type: Gold-plated spring-loaded binding posts
• Product Weight: 22.2 lbs (10.07 kg)
Shipping Weight: 25.6 lbs (11.61 kg)
