The heavy duty professional phone plug series improves on the design of the existing C series by offering the thinnest available A-gauge 1/4" plug with unique Neutrik chuck type strain relief on the market. The slimline shell with a width of 14.5 mm meets the most recent requirements for highest density jackfields (15.88mm jack pitch).

The precise machined one-piece tip contact without rivets makes it unique and avoids hook up in a socket or break off the tip.

The Plug X Series serves all applications such as guitar applications, audio cables, snakes, speakers, amplifiers and mixing desks.



    All metal housing eliminates the plastic cover of the predecessor NP*RCS and improves further durability and EMI protection
    Extra slim 1/4" plug for highest packing density
    Robust diecast shell in stylish design
    Proven chuck type strain relief for reliable cable retention
    Sleek design for best handling convenience
    Precision machined one-piece contacts - avoid hook up of tip contact

Electrical
Contact resistance     depends on mating connector mΩ
Dielectric strength     1 kVdc
Insulation resistance     > 2 GΩ (initial)
Rated current per contact     depends on mating connector A
Rated voltage     < 50 V

Mechanical
Cable O.D.     4 - 7 mm
Lifetime     > 1000 mating cycles
Wiresize     1 mm²
Wiresize     18 AWG
Wiring     Solder contacts

Material
Bushing     Polyacetal (POM) + PU
Contact plating     0.2 µm Au
Contacts     Brass (CuZn39Pb3)
Insert     Polyamide (PA 6.6 30 % GR)
Shell     Zinc diecast (ZnAl4Cu1)
Shell plating     KTL coating
Strain relief     Polyacetal (POM)

Environmental
Standard compliance     IEC 60603-11 / EIA RS-453
Solderability     Complies with IEC 68-2-20
Temperature range     -20 °C to +65 °C
