Cordial CCM 10 FP
Garantujemo najnižu cenu!
- Cara Dušana 85, Niš
- Svetogorska 9, Beograd
XLR to 6.3 mm mono plug
The CCM FP is used for unbalanced transmission of audio signals, for example from a microphone to audio workstations or mixers, when there's only a mono jack input available. Pin 1 and 3 of the XLR plug are soldered together. With a conductor area of 2x 0.22 mm² (both conductors are soldered together) and a spiral shielding of bare CU wires (90% coverage), it ensures undistorted signals in daily use. The moulded-on bend protection sleeve (plug openable) protects the sensitive areas from cable breakage and ensures solid mating cycles.
The hand-soldered REAN® by NEUTRIK® connectors offer the usual NEUTRIK quality at lower prices. The conductor composition of 28 individual strands (0.10 mm diameter each) makes it particularly flexible and easy to wind.
cable essentials cable 1
Jacket PVC
cable assign FP
connector brand REAN ®
plugs
1 XLR female 3-pole
1 1/4" Plug mono
Technical facts
Conductor area 0.22 mm²
AWG AWG 24
Composition of conductor 28 x 0.10 mm
Material bare copper
Conductor resistance < 80 Ohm/km
Shielding spiral shield (90% coverage)
Capacity cond.-cond. (pF/m) < 80 pF/m
category Microphone
diameter 5.9 ± 0.2 mm
Conductor isolation LDPE
