Cordial CFY 3 WMM
Garantujemo najnižu cenu!
- Futoški put 1, Novi Sad
- Ugrinovački Put 10n, Zemun
- Svetogorska 9, Beograd
The Y audio cable is used to transmit the audio signal from 1x 3.5 mm stereo jack plug to 2x male XLR connectors, e.g. to connect a smartphone or notebook directly to certain FOH consoles, to specified power amplifiers or to active speakers.
The split a both ends of the cable is approx. 15 cm long. A red and a black marking directly on the XLR connectors facilitate right/left identification.
As usual, the especially sturdy metal connectors (REAN made by Neutrik®) are hand soldered.
The wire cross section is 2x 0.22mm².
cable essentials cable 2
Jacket PVC
cable assign WMM
connector brand REAN ®
plugs
1 1/8" Plug stereo
2 XLR male 3-pole
Technical facts
Conductor area 0.22 mm²
AWG AWG 24
Composition of conductor 28 x 0.10 mm
Conductor resistance 80 Ohm/km
Shielding spiral shield
Capacity cond.-cond. (pF/m) 80 pF/m
category Microphone
diameter 4.3 mm | 1.69 in
