It is the ideal loudspeaker for background music and spoken message distribution. CM6TSMF has a very good speech intelligibility factor and a surprisingly wide dispersion at the typical speech frequencies, what makes it your number one choice for vocal announcements, evacuation systems...

Thanks to the back can of the loudspeaker, ideal and constant sound is guaranteed. In perforated ceilings, you will not have an acoustic short circuit when installing CM6TSMF as the back can of the loudspeaker prevents this to happen. Another advantage of the back can is that people working or living on the floor above will not hear the music that is playing.

Possible applications for CM6TSMF could be hallways, boutiques and shops, board rooms and offices, emergency and evacuation systems.

outside diameter            205 mm
depth                            120 mm
cutout                            182 mm
installation grip range     1 - 30 mm
loudspeaker system     dual cone
woofer size                    6.5 inch
woofer cone material     coated paper
mounting system          3 screws
100V transformer power taps     6 - 3 - 1.5 watts
SPL 1W/1m               94 dB
max SPL 1m            101 dB
frequency response     90 - 19K Hz
main construction material     steel
grille main material               steel
IP rating                      60
applicable low impedance     no
applicable in 100V               yes
Horizontal dispersion angle 1000 Hz     180°
Vertical dispersion angle 1000 Hz     180°
closest RAL colour (subject to deviations)     RAL9003
Net weight product     1.50 kg
