MARTIN WISMAN DSP 2in 6out AUDIO PROCESOR

Šifra: 11899
Na stanju
48.001,00 rsd
40.000,83 rsd (Bez PDV-a)
Iznos rate:
Prikazana cena je za komad.

Garantujemo najnižu cenu!

Količina

Ukoliko želite da platite na rate kreditnom karticom, molimo Vas da izaberete broj rata.

Važi za kreditne kartice logo_banka

Broj rata:

Dostupno u prodavnici:
  • Svetogorska 9, Beograd
Prijavi povoljniju cenu Obavesti me ako cena padne Postavi pitanje
Opcija:

Key Feature


1) Build in USB & RS 485 COM
2) Program Function; Recall Function; Copy Function; Save Function; Password Function.
3) 6-band EQ: Frequency, gain & Q fact are adjustable;
Gain can be adjusted from -20 dB to +20 dB.
4) 96k Hz sampling frequency, 24-bit A/D and D/A converter, 32-bit DSP digital sound processor
5) Input channel: With 6-band parameter EQ, Delay, polarity
6) Output channel: With 6-band parameter EQ, Gain, Delay, Polarity, Crossover, Limiter/Compressor, Signal select.



Item DP26

Delay Time Step

 Each input channel has independent delay control, Range:0~1000mS;

 21μS step@0~10mS; 84 μS step@ 10mS~20ms;

 0.5mS step@ 20mS~1000mS

Input/Output Polarity

 In-phase(+) or reversed phase(-)

Input EQ

 6-band parameter EQ; Frequency: 20Hz~20KHz; Gain:-20 dB~+20 dB;

 Bandwidth: 0.05oct~3oct

Mute

 Mute with each Input& Output channel

Input Selection

 Each input channel can be selected to each output channel

Output Gain

 Range:-12dB~+12dB, step: 0.1dB

Crossover

 Each output channel can be independently set as LPF and HPF. The parameters

 can be adjusted. Filter type :Linkwitz-Riley; Bessel; Butterworth. The Crossover

 Frequency: 20Hz~20KHz, Slope: 12dB/oct; 18dB/oct; 24dB/oct;48dB/oct.

Limiter

 Limiter with each output channel. The parameters are adjustable:

 Threshold value: -20dBu~+20dBu; step:0.5dBu.

Attack time

 0.3mS~100mS. 0.1mS step@0.3~1mS; 1mS step @1mS~100mS.

 Release Time: Release Time can be set as twice, 4times, 6times, 8times, 16times,

 32times.

Output EQ

 Each output channel has 6-band EQ: 3 modes: Lo-Shelf/Hi-Shelf/Parameter.

 A: Lo-Shelf:

 Slop: 6dB/12dB; Frequency:

 20Hz~20kHz; Gain: -20dB~20dB;

 B: Hi-Shelf:

 Slop: 6dB/12dB; Frequency: 20Hz~20kHz; Gain:-20dB~20dB;

 C: Parameters:

 frequency: 20Hz~20KHz, bandwidth: 0.05oct~3oct; Step: 0.05oct;

 Gain: -20dB~+20dB,

 Step 0.1dB

Processor

 96KHz Sampling frequency, 32-bit Floating-Point DSP

Display

 With 2*24 LCD, 8-LED input/output level. Mute and Editing mode can be displayed.

 Power

 ≤25W

Power Supply

 AC 110V/220V 50Hz/60Hz

Dimension (L×W×H)

 482×232×44mm

Gross Weight

 5.0kg
