Features

• 98 dB SPL 1W / 1m average sensitivity
• 75 mm (3 in) edgewound voice coil
• 500W AES power handling
• Neodymium magnet assembly
• Double Demodulating Rings (DDR) for lower distortion
• Humidity resistant cone
• Ideal for two way systems and for high loading compact subwoofer applications

Specifications

GENERAL SPECIFICATIONS

• Nominal Diameter:380mm (15 in)
• Rated Impedance:8 Ohm
• AES Power:500W
• Program Power:800W
• Peak Power:1600W
• Sensitivity:98 dB
• Frequency Range:40 - 4100 Hz
• Power Compression @-10dB:0,6 dB
• Power Compression @-3dB:1,9 dB
• Power Compression @Full Power:2,8 dB
• Max Recomm. Frequency:1700 Hz
• Recomm. Enclosure Volume:60 ÷ 140 lt. (2,12 ÷ 4,95 cuft)
• Minimum Impedance:6,8 Ohm at 25°C
• Max Peak To Peak Excursion:33 mm (1,3 in)
• Voice Coil Diameter:75 mm (3 in)
• Voice Coil Winding Material:copper
• Suspension:M-roll, Polycotton
• Cone:Curvilinear, Treated paper

THIELE SMALL PARAMETERS

• Fs:36 Hz
• Re:5,5 Ohm
• Sd:0,085 sq.mt. (131,75 sq. in.)
• Qms:5,3
• Qes:0,23
• Qts:0,22
• Vas:206 lt. (7,28 cuft)
• Mms:101 gr. (0,22 lb)
• BL:23,8 Tm
• Linear Mathematical Xmax:± 7,5 mm (± 0,30 in)
• Le (1kHz):1,61 mH
• Ref. Efficiency 1W@1m (half space):98,2 dB

MOUNTING INFORMATIONS

• Overall diameter:387 mm (15,24 in)
• N. of mounting holes:8
• Mounting holes diameter:7,15 mm (0,28 in)
• Bolt circle diameter:370-371 mm (14,57-14,61 in)
• Front mount baffle cutout ø:353 mm (13,9 in)
• Rear mount baffle cutout ø:357 mm (14,06 in)
• Total depth:177 mm (7 in)
• Flange and gasket thickness:11,5 mm (0,45 in)
• Net weight:4,1 kg (9 lb)
• Shipping weight:4,8 kg (10,5 lb)
• CardBoard Packaging dimensions:405 x 405 x 214 mm (15,94 x 15,94 x 8,43 in)
