Eighteensound TWEETER HD110 - 8ohm
*Cena sa popustom može da se ostvari ukoliko se plaća gotovinski, virmanom (preko računa) ili odmah debitnom i kreditnom karticom.
Garantujemo najnižu cenu!
- Svetogorska 9, Beograd
The HD110 is a HF unit suitable for compact size two and three way lightweight systems. It will deliver an unmatched combination of extended linear frequency response and very high efficiency. With a throat exit of 1 inch, the HD110 is developed to match all 1-3/8” screw-in type horns.
The phenolic diaphragm assembly, with its 1 inch edge-wound aluminum voice coil, is capable to handle up to 40W continuous program power for temperature range up to 250°C.
Computer Aided Finite Element Analysis and extensive testing were used to obtain phase plug shape made in high pressure injectionmolded polypropylene foam, designed to assuring maximum strength. Final result is a smooth coherent wavefront in the horn entrance, high thermal stability and manufacturing consistency.
The HD110 compact size and lightweight ceramic magnet assembly is designed to obtain 16KGauss in the gap.
General |
|
| Product type | Compression driver |
| Brand | Eighteen Sound |
| Reference | HD110 |
| Product code | DRV10D110PO08FB |
Informations |
|
| Nominal impedance | 8 ohm |
| Dimensional category | 3.5 inch |
| Manufacturer sensitivity | 109 dB |
| Nominal power handling | 20 W |
| Max power handling | 40 W |
| Bandwidth | 2000÷20000 Hz |
| Recommended min cutoff frequency | 2500 Hz |
| Exit dimension | 1.0 inch |
Datas |
|
| Zmin | 7 ohm |
| Weight | ~0.8 kg |
Dimensions |
|
| Voice coil diameter | 1 inch |
| Outside diameter | 86 mm |
| Depth | 62 mm |
Shape & Materials |
|
| Front chape | Cylindrical |
| Magnet type | Ferrite |
| Winding material | Aluminium |
| Diaphragm material | Fabric |
