Large Music Venues & Outdoor Festivals
12" Woofer
3 x 1" Compression Drivers
Frequency Response: 50 Hz to 20 kHz
2000W Class-D Amplifier
Integrated Advanced Impulse DSP Module
User-Adjustable DRM Control Dashboard
Parallel XLR Input and Output
Universal Power Supply
Tour-Grade Enclosure with Steel Grille
PA Speaker
Configuration |
Active
|
Total Power Capacity |
2000 W Peak
|
Amplifier Class |
Class-D
|
Drivers
HF Driver |
3 x 1" / 25.4 mm
|
LF Driver |
1x 12" / 30.5 cm Woofer
|
Performance
Frequency Response |
50 Hz to 20 kHz -10 dB
|
Maximum SPL |
135 dB
|
Coverage Angle |
110° H x 20° V
|
Connectivity
Audio I/O |
1x XLR 3-Pin Input 1x XLR 3-Pin Output
|
Signal Processing
EQ |
Yes
|
Alignment Delay |
Yes
|
Power
AC Input Power |
Universal: 100 to 240 VAC, 50 / 60 Hz
|
Physical
Mounting |
7 x M10 Pole Socket (Dual Angle)
|
Construction Material |
Metal Grille, Plywood
|
Dimensions |
15.2 x 24.7 x 18" / 386.1 x 627.4 x 457.2 mm
|
Weight |
55 lb / 24.9 kg
|
Packaging Info
Package Weight |
60.15 lb
|
Box Dimensions (LxWxH) |
28.5 x 21.2 x 18.5"
|
