A complete JB Systems® LED PIPE 230V system contains the following components:

    1 or more LED PIPE tubes (can work standalone or can be connected to the dedicated LED PIPE controller)
    1 optional LED PIPE controller (controls the connected led tubes)
    Optional signal extension cables: 1m, 5m or 10m.


Description of the individual LED PIPE units:

    Each LED PIPE uses 144 high efficiency leds. (Red=48, Green=48, Blue=48)
    Each LED PIPE is split up in 16 sections for maximum flexibility while programming patterns!
    A chain of LED PIPE units can be used in 3 ways:
    Standalone without controller: many wonderful build-in patterns, also music activated!
    Standalone with controller: the optional LED PIPE controller can control up to 1000 tubes with additional flexibility.
    DMX control via controller: uses 3 DMX channels
    4 program run modes: auto mode (adjustable speed), Sound mode, dB mode (VU-meter), hold mode.
    Lightweight polymer enclosure with high quality frost lens for indoor use.
    Specially shaped base makes it possible to hide all connection cables nicely behind the units!
    Internal power supply for easy daisy chaining of up to 200 units on only one 230V/16A wall socket!
    Can be easily fixed to walls and ceilings with the supplied wall brackets.
    Suitable for indoor use only.
    Extended life span: 50.000 - 100.000 hours
    Low power consumption: only 18W per tube!
    Optional signal extension cables: 1m, 5m or 10m available.
    Perfect for use in: retail stores, commercial displays, architectural lighting, indoor decoration, clubs, pubs, mobile DJs, trussing, ...
