A signal amplifier.

Compatible with the COLORTAPE and PURETAPE ranges, this signal booster allows to increase the number of ribbons connected in series. Combined with an appropriate power supply, it amplifies the received signal, allowing you to connect more ribbons to a single controller for longer lengths of pipe without discontinuity or difference in brightness.


Requires a power supply
24 V optional

Compatible with tri-color and monochrome ribbons

Up to 182 Watts max.
per output (576 W total)

Seamless installation

Power output: 3 x 8 A

General characteristics:
– Compatible with tri-color and monochrome ribbons
– Compatible with 24 V ribbon power supplies
– Maximum power: 576 W at 24 V
– Control: The TAPEBOOSTER takes the incoming 24 V signal and injects it with the energy from the connected power supply.

– Entries :
– Power supply: 24 V DC, 576 W max
– Ribbon: 24V DC (R, G, B, +)
– Output: Ribbon: 24 ; V DC (R, G, B, +) (400 Hz)
– Possibility to use only one of the 3 channels for monochrome ribbons
– IP20: cannot be used outdoors

Other features:
– Dimensions: 107 x 65 x 24 mm
– Weight : 0,5 kg
– Power supply: DC24V (not included)
