XR 200 BEAM

PR-2203

XR 200 BEAM equipped with Platinum 5R lamp, moving beam light with an unprecedented brightness usually achievable only with far greater wattages. Weighing just 16 kg, produces a perfectly parallel, laser-like beam with an incredible output of 67,765 lx at 20m. With its light weight and modest footprint, XR 200 BEAM is small enough to be fitted anywhere – on trusses at live and TV events, on stage, in showrooms or conference rooms.

Key Features:

• PHILIPS MSD Platinum 5R (8,000K) (189W)
• 1 color wheel with 14 dichroic color filters
• 1 fixed gobo wheel with 17  interchangeable gobos + white
• Beam Angle 0°～4°linearly adjustable
• DMX 0-100% linearly adjustable focus
• Double shutter blades, 0.3~20 F.P.S
• 1 Prism/Frost Wheel with 1 x CTO, 1 x frost, and 1 x 8-facet prism + white
• Channels: Short Mode: 10, Standard Mode: 14
• Pan 540º, Tilt 270º with auto position correction，speed adjustable, with lock mechanism.
• Weight: 16Kg
• IP20
• Fixture usage time and software version display
• Modular construction for easy maintenance

 Standard Accessories:
      G clamps, 2 pcs; XLR connectors, 1 set
      Safety cord, 2 pc;

Optional Accessories: Ω clamps, 2 pcs



Technical Data:

Light Source:
                     PHILIPS MSD Platinum 5R

                     (8,000K, 2,000hrs)

Colors:
1 Color Wheel
14 dichroic colour filters plus white
variable speed and bi-directional rainbow effect
linear colour changing is available

Gobos:
1 Fixed gobo wheel :
17  interchangeable gobos+ white
Shaking and bi-directional whee l scrolling at variable speeds
Gobo changing is available

Prism/Frost Wheel
8-facet rotating Prism(bi-directional with variable speeds)+CTO filter+ Frost Filter + White

Focusing
0-100% linearly adjustable by Dmx

Strobe:
Double shutter blades, 0.3~20 F.P.S

Head Movement:
Pan 540º, Tilt 270º with auto position correction

Beam Angle
0°～4°, Linear zoom

Control:
DMX512, 3 pin and 5 pin interfaces
10 channels in short mode, 14channels in standard mode
Self-test mode

Other Functions:
Adjustable Pan & Tilt speed
Fixture and lamp usage time display
Modular construction for easy maintenance
DMX512 wireless receiver (optional)
DMX512 wireless transmitter (optional)

Housing:
Composite plastic, IP20

Weight:  16Kg

Sizes: please see the drawings below

Light Output:
