iSolution technology allows synchronisation of different types of intelligent iSolution fixtures via either a custom-built iLead DMX-512 controller or in stand-alone mode. iLead (Integrated Lighting System) allows fixtures to be linked and work in synchronisation, regardless of type, including iLead-equipped scanners, moving heads, and colour changers. The iLead controller can also remotely set the DMX addresses of the fixtures. All units are also controllable via any universal DMX-512 controller. Conversely, the iLead controller is a universal DMX-512 controller and can be used with non-iSolution fixtures.
Features:
DMX-512 control channel: 7 Setting and addressing: 4 digit blue LED display LED display with on/off setting function Data in/out: Locking 3-pin XLR iSolution operation Consistant DMX configeration enables iShow to be linked with iRock and iMove DMX address can be set remotely by iLead controller. No need to calculate the DMX channels of each fixture in the chain When the DMX signal is off, the lights will switch to master/slave mode automatically Easy installation, easy addressing, and pre-programmed function Automatic switching between music trigger or auto trigger mode Master/Slave modeBuilt in dynamic lighting shows for instant operation User friendly easy controller: Enjoy various lighting shows at your fingertips Pan: 180 degrees; Tilt 70 degrees Gobo wheel: 7 rotating inter-changeable gobo's plus open including 4 metal, 2 glass and 1 effect gobo Colour wheel: 9 trapezoid dichroic colours plus white; split colours available Rainbow effect in both directions Dimmer/Shutter - independent shutter / variable speed strobe, 1 ~ 10 flashes per second High quality optical lens, dichroic colours and gobo's Beam Angle: 14 degrees
Specification:




Power supply: 240vLamp: MSD 250w / NSD 250wReplacement lamp: Lamp80Dimensions: 695 x 340 x 250mm Weight: 15.0kg
