The Mania EFX600 is a bright, feature-rich 150 W discharge effect light with a dizzying array of razor sharp effects and patterns.

Just like the Mania EFX 500 it features dazzling new graphical looks from a combined colour and gobo wheel cast from a rotating and swivelling mirror drum. Other effects can be achieved through strobe effects, shake function and manual focus. The result is a unique, high powered yet low priced effect light.

Designed primarily for installation use, this versatile effect light includes a number of mounting options yet is durable enough for life on the road. Ideal for any show, club, or party, the compact EFX600 is DMX controllable for ultimate manageability or default to the music or auto trig. Built in macros are included for fast and simple programming.

Combine the superior quality of the Mania brand with the unmatched value of a long-life discharge lamp (6000 hours, included) and users will experience incredible savings over other lights in its class.

And as with all Mania products the EFX600 is officially CE, ETL and CETL approved meaning users are assured of the fixtures' safety and performance.

• 150 W discharge lamp
• Long lamp life (6000 hrs)
• 12 colored gobos
• Manual focus
• Separate shutter for strobe effect
• Rotating and swiveling mirror drum
• All major safety approvals CE, ETL and CETL
• Rigorously tested for total reliability
• DMX, stand alone (music or auto-trig) and master/slave function
• Continuous operation - no cool down time needed
• 12 pre-programmed macros for fast start-up


Physical
Length: 410 mm (16.1 in.)
Width: 500 mm (19.7 in.)
Height: 230 mm (9.1 in.)
Weight: EU model 14 kg (30.9 lbs.), US model 16.5 kg (36.4 lbs.)
All dimensions and weights include the supplied mounting plate.

Lamp
Type: 150 W discharge
Approved lamps: Philips CDM SA-T 150, Osram HSD 150/70
Socket: G12

Dynamic Effects
Motorized rotating parabolic mirror dish
Gobo wheel: 12 colored gobos
Motorized mirror drum: 180° pan (swivel) and 360° tilt (continuous rotation)
Mechanical dimmer/shutter: 0 - 100% dimming, strobe effects

Optics
Manual focus: 2 m (6.6 ft.) - 20 m (65.6 ft.)

Control and Programming
Control options: DMX, stand-alone, synchronized (master/slave)
DMX channels: 6/8
DMX address setting: Onboard control panel with 3-digit display
Macro programs selectable via DMX: 12
Stand-alone trigger options: Music trig (selectable via control panel or via DMX), auto trig
Music trig sensitivity: Electronically adjustable
Protocol: USITT DMX512/1990
Receiver: RS-485
Firmware update: Serial upload via DMX link

Construction
Housing: Steel and aluminum

Installation
Mounting points: Adjustable mounting bracket
Orientation: Any

Connections
AC power input: 3-pin IEC male socket
DMX data in/out: 3-pin locking XLR

Electrical
AC power (US models): 110-120 V nominal, 60 Hz
AC power (EU models): 220-240 V nominal, 50 Hz
Main fuse (110-120 V power): 3.15 AT (slow blow)
Main fuse (220-240 V power): 2 AT (slow blow)

Thermal
Cooling: Forced air
Maximum ambient temperature (Ta max.): 40° C (104° F)
Maximum surface temperature, steady state, Ta=40° C: 80° C (176° F)
Total heat dissipation (calculated, +/- 10% at 110 V, 60 Hz / 230 V, 50 Hz): 650 / 670 BTU/hr.
