Features

100 watt COB 400nm UV LED
Forced air cooling for quiet operation
Electronic dimming and strobe
Bracket suitable for floor or truss mounting
Lightweight construction (4 kg / 8.8 lbs.)

Specifications

Physical
Length: 327 mm (12.8 in.)
Width: 312 mm (12.3 in.)
Height: 207 mm (8.1 in.)
Weight: 4 kg (8.8 lbs.)
Dynamic Effects
Dimming: 0 – 100%, coarse & fine control
Shutter: Strobe & pulse effects, instant open and blackout
Control and Programming
Control systems: USITT DMX512/1990 with RDM
DMX channels: 3
RDM compliance: ANSI/ESTA E.120
Interface: Control panel with backlit LCD display
Photometric Data
* All Photometric Data measured in steady state (30 minutes warm-up time) at 25°C ambient.

Construction
Housing: Cast aluminum
Color: Black
Protection rating: IP20

Installation
Mounting points: Adjustable bracket, surface or truss mount
Location: Indoor location only
Orientation: Any
Minimum distance to combustible materials: 0.1 m (4 in.)
Minimum distance to illuminated surfaces: 0.5 m (20 in.)

Connections
AC power input/output: Neutrik PowerCon
DMX/RDM in/out: 5-pin locking XLR
RUSH PAR 4 UV User Manual 31

Electrical
AC power: 100-240 V nominal, 50/60 Hz
Power supply unit: Auto-ranging electronic switch mode
Typical half-cycle RMS inrush current: 11.2 A
Recommended Miniature Circuit Breaker when power linking: Type D*
Maximum total power consumption: 114 W
*Per IEC 60898/UL489/CSA C22.2 No. 5
Typical Power and Current
100 V, 60 Hz: 114 W, 1.2 A, PF 1.000
120 V, 60 Hz: 114 W, 1.0 A, PF 0.996
230 V, 50 Hz: 114 W, 0.5 A, PF 0.933
Measurements made at nominal voltage. Figures are typical, not maximum, allow for a deviation of +/- 10%.

Thermal
Cooling: Forced air, temperature-regulated
Maximum ambient temperature (Ta max.): 40° C (104° F)
Minimum ambient temperature (Ta min.): 0° C (32° F)
Environmental
RoHS: Compliant
REACH: Compliant
WEEE: Compliant
Proposition 65: Compliant
