Art Pro Audio Dual Limiter - Classic PWM Limiter
Garantujemo najnižu cenu!
- Ugrinovački Put 10n, Zemun
- Svetogorska 9, Beograd
The DUAL LIMITER has a unique design that will enhance the sonic textures of your audio system for years to come. Developed in partnership with studio and live-sound engineers, the DUAL LIMITER is very musical.
The heart of the Dual Limiter is a unique PWM gain control circuit. Combined with its’ intelligent detector, the result is a Classic sounding compressor/ limiter without the traditional noise and distortion artifacts.
Key Features
- Two channels of dynamics processing
- Selectable stereo linking of channels
- XLR balanced inputs and outputs
- 1/4″ TRS active balanced inputs and outputs
- Variable Attack and Release controls
- Selectable Slope
- Hardwire bypass
- 5-segment Gain Reduction LED array
- Internal power supply
- 3-year parts and labor warranty
Specifications
| Equivalent Input Noise | -97dBu (20-20kHz) |
| Input Impedance | 20k Ohms |
| Output Impedance | Balanced/Unbalanced – 150 Ohms |
| Maximum Input Level | +20dBu |
| Maximum Output Level | +20dBu |
| Overall Gain | +40dB max |
| Frequency Response | 10Hz to 30kHz (+/- 1dB) |
| Dynamic Range | >105dB (20-20kHz) |
| Attack Time | 0.5mSec. to 50mSec., variable |
| Release Time | 100mSec. to 3 Sec., variable |
| Slope | 4:1 or >20:1, switchable (OR 2:1 or 1.5:1 when patching output to det. loop input) |
| Total Harmonic Distortion | 0.03% (typical) @ 0dBm Out |
| Power Requirements | USA – 105 to 125 VAC / 60 Hz, 1/2A fuse, <15W Export units configured for country of destination. |
| Dimensions | 1.75″ H x 19″ W x 5.9″ D (44.5mm x 482.6mm x 150mm) |
| Weight | 4.7 lbs (2.1 kg) |
| Notes | 0 dBu = 0.775 VRMS
ART maintains a policy of constant product improvement. ART reserves the right to make changes in design, or make additions to, or improvements upon, this product without any obligation to install same on products previously manufactured. Therefore, specifications are subject to change without notice. |
