The DR-60D MKII is a compact 4-track audio recorder for dedicated use with a digital single-lens reflex (DSLR) or digital single-lens mirrorless (DSLM) camera as a video system. It can be mounted directly to the camera and offers various audio inputs and outputs to allow the recording of high-resolution audio material in parallel to, but separated from the camera and its video data.
The recorder features Tascam original HDDA microphone preamps which are known for high S/N ratio, low input-referred noise and low distortion. Recordings can be made at 44.1/48/96 kHz, 16/24-bit in WAV or BWF format. In addition to ordinary stereo recording, it is possible to record up to four channels simultaneously which can then be mixed down to a stereo signal. Recording levels can be adjusted independently for inputs 1, 2 and 3–4 and the Dual Recording function allows two files to be recorded in parallel at different levels.
The DR-60D MKII can output high-quality audio to a DSLR/DSLM camera to be recorded there as a reference track, and a camera input enables convenient monitoring of audio sent from a DSLR camera. Mid-side decoding, slate tone functions (automatic/manual), selectable time delay and other functions for convenient recording are also available.
Features at a glance
Changes since the previous model are marked red
- Compact, high-quality audio recorder designed to be used in combination with a DSLR camera
- Uses an SD/SDHC card as recording medium
- High-quality recording inputs through Tascam original High Definition Discrete Architecture (HDDA) microphone preamps
- In addition to ordinary stereo recording, simultaneous recording of up to four channels is possible
- Four channels can be mixed down to a stereo signal
- Recording levels can be adjusted independently for inputs 1, 2 and 3–4
- Dual recording function allows two files to be recorded simultaneously at different levels
- Recording at 44.1/48/96 kHz, 16/24-bit, linear PCM (WAV format)
- Broadcast Wave Format (BWF) supported as WAV recording format
- New, smooth XLR/TRS combo jacks
- XLR mic/line inputs can provide phantom power (+24V/+48V)
- TRS mic/line inputs support +24 dBu input when used as line inputs
- "HI+PLUS" setting allows a maximum input gain of 64 dB
- Stereo mini jack input supports mics that require plug-in power, allowing the input of video mics and other high-output mics (+10 dBV maximum input level)
- Low-cut filter conveniently reduces low-frequency noise (40 Hz, 80 Hz, 120 Hz)
- High-quality audio can be output to a DSLR camera for recording
- Two camera outputs with different levels allow audio signal to be sent to a line or mic input of the camera
- Camera input enables convenient monitoring of audio from a DSLR camera
- Selectable mid-side decoding for use with MS microphone setups
- Slate tone functions (automatic/manual) to simplify synchronization with video files when editing
- Pre-recording function allows the unit to record the two seconds of sound before recording is activated
- Auto recording function to start start and stop recording by input level
- A new file can be created during recording (manually or by file size)
- Self-timer function to start recording after a set period of time
- Jump-back function allows the last several seconds of the currently played file to be replayed again by simply pressing a button
- Selectable delay to eliminate time lags caused by differences in the distances of two input sources
- QUICK button allows easy access to various functions
- Divide function allows files to be split where desired
- Mark function convenient for moving to specific locations
- Equalizers for playback, and level alignment function to enhance the perceived overall sound pressure
- File name format can be set to use a user-defined word or the date
- Resume function to memorize the playback position before the unit is turned off
- Line output and headphones output with individual level controls (3.5-mm jack)
- 128 x 64 pixel LC display with backlight
- USB 2.0 port
- Stand adapter (¼ inch) on bottom side to attach the unit to a tripod
- DSLR bracket for easy camera attachment and removal with a coin
- Dedicated remote control jack (for use with RC-10 and RC-3F (sold separately))
- Hold switch to prevent accidental operation
- Handles on the front left and right sides protect the screen and can be used to attach a shoulder belt
- Operates on four AA batteries, an optional AC adaptor (Tascam PS-P520E), optional external battery pack (Tascam BP-6AA) or USB bus power
- Power source switches automatically from external to internal when necessary (with pop-up message on display)
Specifications
| General | |
|---|---|
| Recording media | SD card (64 MB – 2 GB) SDHC card (4–32 GB) |
| Audio file compatibility | WAV: 44.1/48/96 kHz, 16/24-bit BWF (Broadcast Wave Format): 44.1/48/96kHz, 16/24-bit |
| Number of channels | 4 channels (stereo x 2) |
| Analogue audio inputs and outputs | |
|---|---|
| Mic/Line input 1/L, 2/R (switchable phantom power) | XLR-3-31 6.3-mm standard TRS Jack |
| Input switch set to MIC or MIC+PHANTOM | |
| Input impedance | 2 kΩ |
| Phantom Power | 48 V ±4 V (10 mA/channel) or 24 V ±4 V (10 mA/channel) |
| Maximum input level | 0 dBu |
| Minimum input level | −72 dBu |
| Mic input gain (input level knob at maximum) | LOW: +11 dB MID: +36 dB HIGH: +52 dB HIGH+PLUS: +64 dB |
| Input switch set to LINE | |
| Input impedance | 10 kΩ or higher |
| Nominal input level | +4 dBu |
| Maximum input level | +24 dBu |
| Mic/Line input 3-4 (supports plug-in power) | 3.5-mm stereo mini jack |
| Input impedance | 10 kΩ |
| Maximum input level | +10 dBV |
| Minimum input level | −50 dBV |
| Mic input gain (input level knob at maximum) | LOW: +3 dB HIGH: +26 dB HIGH+PLUS: +38 dB |
| CAMERA IN jack | 3.5-mm stereo mini jack |
| Input impedance | 10 kΩ |
| Nominal input level | −10 dBV |
| Maximum input level | +6 dBV |
| CAMERA OUT (LOW) jack | 3.5-mm stereo mini jack |
| Output impedance | 200 Ω |
| Nominal output level | −50 dBV |
| Maximum output level | −30 dBV |
| Headphones output | 3.5-mm stereo mini jack |
| Maximum output power | 50 mW + 50 mW |
| CAMERA OUT (HIGH)/LINE OUT jack | 3.5-mm stereo mini jack |
| Output impedance | 200 Ω |
| Nominal output level | −10 dBV |
| Maximum output level | +10 dBV |
| Other inputs and outputs | |
|---|---|
| USB | USB Mini-B Type |
| Format | USB 2.0 HIGH SPEED mass storage class |
| REMOTE jack | 2.5-mm TRS jack |
| Audio performance | |
|---|---|
| Frequency response | 20 Hz – 20 kHz, +0.5/–2 dB (LINE IN or MIC IN to LINE OUT, Fs 44.1/48 kHz, JEITA) 20 Hz – 40 kHz, +0.5/–3 dB (LINE IN or MIC IN to LINE OUT, Fs 96 kHz, JEITA) |
| Distortion | 0.02% or less (LINE IN or MIC IN to LINE OUT, Fs 44.1/48/96 kHz, JEITA) |
| S/N ratio | 92 dB or more (LINE IN or MIC IN to LINE OUT, Fs 44.1/48/96 kHz, JEITA) |
| Equivalent input noise | –120 dBu or less |
| Note for JEITA | Conforming to JEITA CP-2150 |
| Computer compatibility | |
|---|---|
| Windows | Pentium 300 MHz or faster 128 MB or more memory |
| Mac | Power PC, iMac, G3, G4 266 MHz or faster 64 MB or more memory |
| Recommended USB port | USB 2.0 |
| Recommended USB host controller | Intel chipset |
| Supported operating systems | Windows XP, Windows Vista, Windows 7, Windows 8 (including Windows 8.1), Mac OS X 10.2 or later |
| Power supply and other specifications | |
|---|---|
| Power supply | Four AA batteries (Alkaline or Ni-MH) USB bus power supplied from a computer AC adaptor (TASCAM PS-P515U, sold separately) External battery pack (TASCAM BP-6AA, sold separately) |
| Power consumption | 5.4 W (maximum) |
| Dimensions (W × H × D) | 133 mm × 93 mm × 78 mm (with the top adapter attached) |
| Weight | 510 g (without batteries) |
| Operating temperature range | 0–40 °C |
