INPUTS
MIC/LINE (mono)
• Connectors: 2 XLR/TRS combo jacks (XLR: 2 HOT, TRS: TIP HOT)
• Input gain: Adjustment unnecessary (dual A/D converter circuits used)
• Input impedance: MIC: 2.7 kΩ or more
LINE: 1 kΩ or more
• Maximum input level: MIC: +4 dBu
LINE: +24 dBu
• Phantom power: +48 V
Channel total 10 mA or less
• Equivalent input noise: MIC: –122 dBu or less (IHF-A) at 150Ω input
LINE: –100 dBu or less (IHF-A) at 600Ω input
MIC/LINE IN jack
• Connector: Stereo mini jack
• Input impedance: 2 kΩ
• Plug-in power: 2.5 V

OUTPUTS
PHONE / LINE OUT jack
• Connector: Stereo mini jack
• Maximum output level: 20 mW + 20 mW (when 32 Ω load)
• Output impedance: 10 Ω or less
Built-in speaker
• Type: 20 mm × 30 mm elliptical dynamic speaker
• Effective maximum output: 250mW

RECORDER
• Recording format: WAV
44.1, 48 or 96 kHz / 32-bit float
Stereo / Mono
BWF and iXML formats supported
• Recording media: 4 – 32GB cards compatible with the microSDHC specification
64GB – 1TB cards compatible with the microSDXC specification

DISPLAY
• OLED: 128 x 64

USB
• Connector: USB Type-C
• Use a USB cable that supports data transfer.
• Audio interface: USB Audio Class 1.0
• Input and output channels: 2 in / 2 out (Stereo)
• Sampling frequencies: 44.1, 48 kHz
• Bit depths: 16-bit, 32-bit float
• File transfer: USB 2.0 High Speed

POWER
• 2 AA batteries: Alkaline, Lithium, or Rechargeable NiMH
• AC adapter: ZOOM AD-17: DC 5 V/1 A
• USB bus power is supported.
