Features
• Cardioid pick-up pattern
• Modular design
• Wide frequency response 30 to 50.000 Hz
• Symmetrical transducer with 2 backplates providing extremely low distortion
• Extremely low inherent self-noise
• Accurate directional pattern
• Non reflective Nextel coating
• Ideal as a spot microphone and for surround recordings
• Also available in stereo pairs

Tech Specs
Product
Polar pattern: Cardioid
Transducer principle: RF condenser microphone
Frequency Specifications
Frequency response: 30 - 50000 Hz
Acoustic Properties
Equivalent noise level (db): 13 dB
Inputs/Outputs
Audio output: XLR-3M balanced, transformerless, floating
Battery & Power
Phantom powering: 48 V +/- 4 V
Electrical Properties
Nominal impedance: 25 Ω
Min. terminating impedance: 1000 Ω
Dimensions
Dimensions: Ø 19 mm, L 41 mm (74 mm with XLR module)
Height (mm): 82
Length (mm): 245
Master carton height (mm): 388
Master carton length (mm): 354
Master carton weight (g): 517.558
Master carton width (mm): 354
Weight (g): 25 g (55 g with XLR module)
Width (mm): 170
Package Depth (mm): 68
Package Height (mm): 351
Package Weight (g): 858
Package Width (mm): 137
