Features
• Dual-diaphragm true condenser microphone
• Five switchable polar patterns
• 3-position switchable low cut/roll-off filter
• 3-position pad switch
• Two 24-carat gold plated 1 inch diaphragms
• Shock-mounted capsule
• Rugged metal housing
• Safely sheltered electronics
• Designed and made in Germany

Tech Specs
Product
Transducer principle: externally polarised condenser microphone, 1‘‘ diaphragm
Frequency Specifications
AF sensitivity (mV/Pa): 14,1 mV /-37 dB dBV
Frequency response: 20 Hz – 20 kHz
Acoustic Properties
Dynamic range (>): 132 dB
Equivalent noise level (db): 10 dB(A)
Low-cut filter: Switchable: Low cut: 60 Hz, -18dB/Octave / Roll off: 100 Hz, -6dB/Octave
Ambient Conditions
Operating temperature (C): 0°C to +40°C
Electrical Properties
Nominal impedance: 50 Ohms
Min. terminating impedance: 1000 Ohms
Dimensions
Dimensions: 160 x 57 mm (L x D)
Height (mm): 80
Length (mm): 260
Master carton height (mm): 288
Master carton length (mm): 584
Master carton weight (g): 527.558
Master carton width (mm): 584
Weight (g): 485 g
Width (mm): 120
Package Depth (mm): 120
Package Height (mm): 80
Package Weight (g): 725
Package Width (mm): 260
