Universal Audio Apollo x16 Thunderbolt 3
Šifra:
358.800,00 rsd
299.000,00 rsd (Bez PDV-a)
Iznos rate:
Prikazana cena je za komad.
Garantujemo najnižu cenu!
Born from the ever-popular Apollo line of interfaces used on loads of Grammy-winning albums and chart-topping songs, the Universal Audio Apollo x16 rackmount 18x20 Thunderbolt 3 audio interface combines the sound, feel, and flow of analog studio recording with upgraded clocking, surround monitoring, a robust bundle of 16 stellar UAD plug-ins, and 50% more DSP than earlier Apollos thanks to its supercharged HEXA Core real-time UAD processing.
Furnished with Universal Audio's flagship 24-bit / 192 kHz conversion, the Apollo x16 gives engineers in commercial recording studios, concert tours, and postproduction facilities the confidence of recording and mixing with detailed imaging, unbelievably low distortion (-129 dB), and unmatched dynamic range (133 dB). Additionally, its switchable headroom setting facilitates proper level-matching with large-format consoles and a variety of boutique and pro-level audio equipment.
The interface features 16 balanced analog line-level inputs and outputs on DB25 connectors, perfect for patching in external mic preamps and custom signal chains or hooking up to a bunch of channels on a classic analog mixing board. You also get a pair of XLR monitor outputs and stereo AES/EBU I/O, which can be utilized when you need to connect a dedicated feed to a mastering system or if you wish to incorporate alternative stereo converters. Utilize the BNC wordclock input and output jacks to accurately clock to house sync or lock other digital equipment to the Apollo x16.
The built-in HEXA Core processing utilizes six DSP chips, granting 50% more DSP than earlier Apollos and the ability to monitor and record audio using classic analog emulations with near-zero latency and no burden on your computer's CPU. The included Realtime Analog Classics Plus plug-in bundle empowers you with 16 top-notch plug-ins ranging from compressors and EQs to virtual guitar/bass amps and time-based processors. The included Console application provides control and recall of all interface and UAD plug-in settings including channel-strip presets, drag-and-drop functionality, and dynamically resizable windows.
Mac and Windows drivers ensure compatibility with all major DAWs including Pro Tools, Logic Pro, Cubase, Ableton Live, and more. The interface also integrates seamlessly with LUNA, Universal Audio's free Mac-based, single-window recording system with unlimited track counts and full Audio Units support.
The Apollo x16 offers a comprehensive monitor section with talkback functionality and dedicated front-panel controls as well as full input and output metering capabilities. In addition to the dedicated stereo XLR monitor output, the 16 line outputs can feed alternate monitors and outboard processors. In fact, the Apollo x16 is capable of acting as a 7.1 surround sound monitor controller.
At any point, you can increase the power and capability of the Apollo x16 through integration of qualified Universal Audio hardware. Up to four Apollo interfaces and six total UAD-2 devices can be combined, allowing Thunderbolt users the ability to expand their I/O and DSP without abandoning the Apollo x16. The two Thunderbolt 3 ports are backward compatible with Thunderbolt 1 and 2 via a qualified adapter (available separately).
The Power of Apollo X
Track, overdub, and mix with UA's flagship AD/DA conversion and DSP-powered plug-ins
Dual-Crystal clocking features dedicated crystals for 44.1 / 88.2 / 176.4 kHz and 48 / 96 / 192 kHz sample rates, resulting in stunningly low jitter (under 10 picoseconds) for pure, artifact-free recordings and solid stereo imaging
HEXA Core UAD processing for tracking through models of vintage compressors, EQs, tape machines, mic preamps, and guitar amps with near-zero latency and 50% more DSP than earlier Apollos, all with no burden on your computer's CPU
Two high-speed Thunderbolt 3 ports for connectivity with Mac and Windows computers (Thunderbolt cable available separately)
1 RU rackmount form factor with reliable AC powering (secure locking external power supply included)
Free, industry-leading phone/online technical support from knowledgeable audio engineers
I/O for the Commercial Studio
18x20 audio interface with 16 balanced analog line-level inputs and outputs via DB25 multipin connectors
Stereo XLR monitor output with level control
Selectable operating level of +20 dBu or +24 dBu for out-of-the-box compatibility with professional mixing consoles and other high-end pro audio equipment
Stereo AES/EBU input and output on XLR jacks, ideal for interconnecting mastering converters
BNC wordclock I/O with selectable 75-ohm termination, crucial for accurate synchronization with other digital equipment
Workflow-Enhancing Features
Built-in multichannel monitor controller with assignable dim or mono mode, works with main, alt, or even 7.1 surround sound speaker setups
Integrated talkback and cues for easy communication and slate functionality
Extensive front-panel metering and indication
Expandable I/O and DSP
Cascade up to four Thunderbolt-equipped Apollo interfaces and six UAD-2 Thunderbolt devices for expanded I/O and DSP
Backward-compatible with Thunderbolt 1 and 2 via a qualified adapter (available separately)
16 Powered Plug-Ins
Includes Realtime Analog Classics Plus plug-in bundle, which supports VST, RTAS, Audio Units, and AAX 64-bit for compatibility with all major DAWs
UA 610-B Tube Preamp and EQ
Marshall Plexi Classic Guitar Amp
Ampeg SVT-VR Classic Bass Amp
UA 1176LN Limiting Amplifier (Legacy)
UA 1176SE Limiting Amplifier (Legacy)
Pultec EQP-1A EQ (Legacy)
Pultec Pro EQ (Legacy)
Teletronix LA-2A Leveling Amplifier (Legacy)
Raw Distortion
Fairchild 670 Compressor (Legacy)
Precision Enhancer Hz
Precision Channel Strip (Precision Mix Rack Collection)
Precision Reflection Engine (Precision Mix Rack Collection)
Precision Delay Mod (Precision Mix Rack Collection)
Precision Delay Mod L (Precision Mix Rack Collection)
RealVerb Pro Custom Room Modeler
Integration with LUNA Recording System for Mac
Works with all major DAWs including Logic Pro, Ableton Live, Pro Tools, and more
Apollo x8p becomes a fully integrated recording system with LUNA, a powerful free recording application for Mac from Universal Audio
Bolstered by Accelerated Realtime Monitoring, LUNA lets you track and mix in an intuitive single-window workflow with unlimited track counts, full Audio Units plug-in support, and access to a suite of exclusive LUNA instruments and extensions such as Studer Multitrack Tape and Neve Summing
Universal Audio Apollo X16T Specs
Form Factor Rackmount
Display 18 x Multi-Segment LED Meter
Channels of I/O Analog:
16 Inputs / 18 Outputs at 192 kHz
Digital:
2 Inputs / 2 Outputs at 192 kHz
Maximum Sampling Rate 192 kHz / 24-Bit
Number of Mic Preamps None
Solo/Mute Mute per Master
Pad None
High-Pass Filter None
Expansion Slots None
Connectivity
Analog Audio I/O 2 x DB-25 25-Pin Balanced Line/8-Channel Input
2 x DB-25 25-Pin Balanced Line/8-Channel Output
2 x XLR 3-Pin Balanced Monitor Output
Phantom Power None
Digital Audio I/O 1 x XLR 3-Pin AES3 Input
1 x XLR 3-Pin AES3 Output
Host Connection / USB 1 x USB Type-C (Thunderbolt 3)
USB (Non-Host) None
Sync I/O 1 x BNC Word Clock Input
1 x BNC Word Clock Output
Network I/O None
MIDI I/O None
Wireless Connectivity None
Memory Card Slot None
Performance
Frequency Response Line Inputs:
20 Hz to 20 kHz ±0.05 dB
Line Outputs:
20 Hz to 20 kHz ±0.02 dB
Monitor Outputs:
20 Hz to 20 kHz ±0.2 dB
Maximum Input Level Line Inputs:
+24 dBu (Balanced, +4 dBu)
+6.2 dBV (Balanced, -10 dBV)
Maximum Output Level Line/Monitor Outputs:
+24 dBu (+4 dBu)
+10 dBV (-10 dBV)
Impedance Line Inputs:
10 Kilohms
Line/Monitor Outputs:
100 Ohms
Word Clock :
75 Ohms
Dynamic Range Line Inputs:
124 dBA
Line Outputs:
127 dBA
Monitor Outputs:
133 dBA
THD+N Line Inputs:
-115 dB / 0.00018% (1 kHz, +23 dBu Input)
Line Outputs:
-123 dB / 0.000068% (1 kHz, at -1 dBFS)
Monitor Outputs:
-129 dB / 0.000037% (1 kHz, at -1 dBFS)
Digital Audio
Sample Rates Up to 192 kHz
Sample Rate Conversion None
Bit Depths 24-Bit (AD/DA Conversion)
Latency 1.1 ms at 96 kHz (Input to Output)
Sync Sources AES3, Internal, Word Clock
Clocking Word Clock:
Input Termination: 75 Ohms (Switchable)
Lock Range: 44.1 to 192 kHz ±4% of Sample Rate
Compatibility
Included Software LUNA Mac Only
Compatible Software (Not Included) Any Core Audio (Mac) Compliant Software
Supported Drivers/API & Plug-Ins Proprietary
Processor Requirement Intel Core i7
Storage Requirements 6 GB
Mobile Device Compatibility None
Required Hardware Available Thunderbolt 3 Port
Thunderbolt Cable (Not Included)
Internet Connection Required for Registration and Software/Driver Download
Power
Power Requirements AC/DC Power Adapter (Included)
AC Input Power 100 to 240 VAC, 50 / 60 Hz
AC/DC Power Adapter 12 VDC at 6 A (Included)
Power Consumption 30 W (Typical)
72 W (Maximum)
Physical
Rackmount Size 1 RU
Operating Temperature 32 to 104°F / 0 to 40°C
Dimensions 19 x 13.5 x 1.8" / 48.3 x 34.3 x 4.6 cm (Including Controls and Protrusions)
Weight 9.0 lb / 4.1 kg
Packaging Info
Package Weight 17.15 lb
Box Dimensions (LxWxH) 23 x 16.5 x 6.8"
