Apollo x8p allows music engineers, producers, and project studios to track, overdub, and mix with elite-class A/D and D/A conversion, HEXA Core UAD plug-in processing, Dual-Crystal clocking, and 7.1 surround sound monitoring — all in a sleek rackmount Thunderbolt 3 audio interface for Mac or Windows.

Built upon UA’s 60-year heritage of audio craftsmanship, this 18 x 22 interface laps the competition with eight Unison™-enabled mic preamps, all-new HEXA Core processing — yielding 50% more DSP for running UAD Powered Plug-Ins in real time — plus it includes LUNA Recording System, giving you a fully‑integrated music production application.
Record with elite-class A/D and D/A conversion — nearing the widest dynamic range and lowest noise available, at any price
Mix with powerful HEXA Core processing, featuring 6 UAD DSP chips for running more UAD Powered Plug-Ins in real time
Track through 8 Unison-enabled mic preamps — with fully authentic emulations from Neve,® API,® Manley,® Helios,® and more
Includes LUNA Recording System — a fully-integrated and inspiring music production applicationElite-Class A/D and D/A Conversion
With thousands of hit songs and hundreds of Grammy-winning albums under their belt, Apollo interfaces are no strangers to tracking stellar-sounding records. To improve on the previous generation Apollo interfaces’ class-leading audio conversion, UA engineers obsessively auditioned the latest A/D and D/A converters — ultimately pairing elite-class 24-bit/192 kHz converters with all-new analog circuitry for an ultra-pristine signal path.

The Apollo X series also introduces new Dual-Crystal clocking — featuring dedicated crystals for 44.1/88.2/176.4k and 48/96/192k sample rates — resulting in stunningly low jitter, measured at less than 10 picoseconds. This translates into pure, artifact-free recordings and solid stereo imaging you can trust.

With 129 dB dynamic range and -119 dB THD+N, Apollo x8p’s open, natural sound rivals any dedicated high-end converter on the market — regardless of price — and is the perfect starting point for applying UAD processing.
Realtime UAD HEXA Core Processing
Apollo x8p features new HEXA Core processing, with six DSP chips and 50% more UAD plug-in processing power than previous Apollos. This lets you run more UAD plug-ins, whether you’re tracking in real time with channel strips from Neve, Manley, or API, or running high UAD plug-in counts when mixing in your DAW.

From the tube warmth of Pultec EQs on guitars to the musical tube limiting of the LA-2A on vocals, or the pump of a genuine 1176 or Fairchild 670 tube compressor on drums, your recordings will take a giant leap forward with a rich, three-dimensional analog sound that UAD plug‑ins provide.
Unison Technology: The Genuine Sound of Neve, API & Manley Preamps
Perfect for engineers, producers, and project studio owners, Apollo x8p features eight Unison-enabled mic preamps, letting you track large projects through exacting mic preamp emulations from Neve, API, Manley, Helios, SSL, and Universal Audio. A Universal Audio exclusive, Unison technology nails the tone of these sought-after tube and solid state mic pres — including their input impedance, gain stage “sweet spots,” and the component-level circuit behaviors of the original hardware.

The secret to Unison is its hardware-software integration between Apollo’s mic preamps and its onboard HEXA Core DSP Acceleration. Simply place a Unison preamp plug-in on your mic input in Apollo Console software, and it physically reconfigures the Apollo interface's impedance — so you can tap into the classic sounds of the world’s most recorded mic preamps.
Apollo x8p Features & Specs

16 x 22 Thunderbolt 3 audio interface with class-leading 24-bit/192 KHz conversion (backwards compatible with Thunderbolt 1 & 2 on Mac)

Realtime UAD HEXA Core Processing for tracking through UAD plug-ins at near-zero latency, regardless of audio buffer size

8 Unison-enabled mic preamps with realtime preamp emulations from Neve, API, SSL, Manley, Universal Audio, and more†

Produce with LUNA Recording System — a fully-integrated recording application made for Apollo (Mac/Thunderbolt)

Surround monitor controller up to 7.1 format

Includes the "Realtime Analog Classics Plus" UAD plug-in bundle. Other UAD plug-ins sold separately.

UAD HEXA Core processing onboard for additional mixing horsepower for Pro Tools, Logic, Cubase, Ableton, and other major DAWs

Combine up to 4 Thunderbolt-equipped Apollos and 6 total UAD devices

Selectable +24 dBu operation for easy compatibility with professional mixing consoles and tape machines

Convenient front panel monitoring functions including Alt Speakers, Talkback mic, and assignable Dim or Mono

Free, industry-leading technical support — on the phone and online — from knowledgeable audio engineers

Interface Specifications
Inputs
Combo Mic/Line Inputs 8 Balanced XLR/TRS
DB25 Line Inputs 8 Balanced via 25-pin D-sub
Instrument (Hi-Z) Inputs 2 Unbalanced ¼" TS
Digital Inputs (Optical TOSLINK) ADAT: 8 channels @ 44.1 – 96 kHz
ADAT: 4 channels @ 176.4 – 192 kHz
S/PDIF: 2 channels @ 44.1 to 96 kHz
(Switchable ADAT or S/PDIF)
A to D Conversion
Mic Preamps Dynamic Range: 122 dB (A-weighted)
THD+N: -115 dB (0.00019%)
Frequency Response: 20 Hz – 20 kHz, ±0.05 dB
Line Inputs Dynamic Range: 123 dB (A-weighted)
THD+N: -113 dB (0.00022%)
Frequency Response: 20 Hz – 20 kHz, ±0.04 dB
Outputs
DB25 Line Outputs 8 Balanced via 25-pin D-sub
Monitor Outputs 2 Balanced ¼" TRS
Headphone Outputs 2 Stereo ¼" TRS
Digital Outputs (Optical TOSLINK) ADAT: 8 channels @ 44.1 – 96 kHz
ADAT: 4 channels @ 176.4 – 192 kHz
S/PDIF: 2 channels @ 44.1 to 96 kHz
(Switchable ADAT or S/PDIF)
D to A Conversion
Line Outputs Dynamic Range: 127 dB (A-weighted)
THD+N: -118 dB (0.00011%)
Frequency Response: 20 Hz – 20 kHz, ±0.07 dB
Monitor Outputs Dynamic Range: 129 dB (A-weighted)
THD+N: -118 dB (0.00012%)
Frequency Response: 20 Hz – 20 kHz, ±0.06 dB
Headphone Outputs Dynamic Range: 125 dB (A-weighted)
THD+N: -102 dB (0.00080%)
Frequency Response: 20 Hz – 20 kHz, ±0.05 dB
