Highlights
• Best-in-class Apogee conversion and mic preamp technology
• Up to 24 bit / 192kHz recording
• 2×4 USB-C audio interface
• 2 USB Type-C Ports
• 2x ¼” Instrument input
• 2x ¼” Balanced outputs
• 1/4” Headphone output
• Low profile design with aluminum body
• Bus powered
• On-board hardware DSP for low-latency recording with Apogee FX
• Symphony ECS Channel Strip – Hardware DSP FX (Native plugin sold separately)

Specifications
MIC PRE
Gain: Up to 65dB
EIN: 128dB (un-weighted) @ 60dB, 150 Ohm input
Max Input Level: +18dBu
Input Impedance: 4k Ohm

HI-Z
Max input level: 14dBu
Input Impedance: >20M Ohm

A/D CONVERSION
Max input level +4dBu: +18dBu
Max input level (-10dBV ref): +6dBV
Input impedance: 4KOhm
Freq resp 20 Hz -20Khz: > +/-0.2dB (@44.1Khz)
Rel. THD + N: -103dB
Dyn. Range: 119dB (A-weighted)

D/A CONVERSION
Max output level (+4dBu ref): +18dBu
Max output level (-10dBV ref): +6 dBu
Line output impedance: 50 Ohm
Freq resp 20Hz -20 Khz: > +/- 0.05dB
Rel. THD+N : -110dB
Dyn Range: 125dB (A-weighted)

HEADPHONE OUT
Max output level headphones: +18dBu
Headphone output impedance: < 0.5 Ohm Ohm
Rel. THD+N : -109dB with 600 Ohm Load
Dyn Range: 124dB (A-weighted)

PRODUCT SIZE
Weight: 2lbs. / 0.95 kg
Dimensions: 8.85” x 7” x 3.54” / 22.5cm x 18cm x 9cm

Compatibility
• macOS: 10.15 and later
• iOS / iPad OS: 15 and later*
• PC: Windows 10 Anniversary update or later
*All iPads with an USB-C port are compatible with BOOM.
Devices with a Lightning port require the camera connection kit and a powered USB-A hub.

Bundled Software
Included With Duet 3 LE*:
• Apogee Pultec EQP-1A
• Apogee Pultec MEQ-5
• Melodyne 5 Essentials
• Ableton Live Lite free
• 50% off coupon for any Apogee plugin or plugin bundle
• 1 Month Free Membership of SoundGym
*All offers require registration of a new Duet 3 LE on Apogee website
